| SPEED |
|---|
| Wireless Speed |
300 Mbps |
| LAN/WAN |
10/100 Mbps Auto-Negotiation (Auto MDI/MDIX) LAN Ports; 10/100 Mbps Auto-Negotiation WAN/LAN Interchangeable port (Auto MDI/MDIX) |
|
| ADDITIONAL FEATURES |
|---|
| Other Features |
Bandwidth Control; Basic Features: Wireless Radio: On/Off; SSID Broadcast: On/Off; WDS: On/Off; Channel: Auto 1-13; Network Mode: 11b only, 11g only, 11n only, 11bg Mixed; Channel Bandwidth: Auto, 20 MHz, 40 MHz; Transmission Media: Cat.5, Cat.5e, Cat.6, Phone Cable; Operating Mode: Wireless ADSL/ADSL2+ Modem Router, WDS; DHCP Server, Virtual Server, 3G Access; VPN Pass-through: PPPTP, L2TP, Ipsec; Bandwidth Control, Static Route, Logs, VLAN: 802.1Q VLAN |
| SSID Support |
Yes |
| Certification |
FCC, CE, RoHS |
|
| OPERATING CONDITIONS |
|---|
| Operating Humidity |
Operating Humidity: 10% to 90% RH (Non-Condensing), Storage Humidity: 5% to 90% RH (Non-Condensing) |
| Temperature |
Operating Temperature: 0 to 40 Degree C, Storage Temperature: -40 to 70 Degree C |
|
| DIMENSIONS |
|---|
| Height |
34.47 mm |
| Width |
111.16 mm |
| Depth |
171.61 mm |
|
| Other Details |
|---|
| Country of Origin or Manufacture or Assembly |
India |
| Common or Generic Name of the commodity |
Routers |
| Manufacturer's Name & Address |
|
| Packer's Name & Address |
|
| Marketer's Name & Address |
|
| Importer's Name & Address |
|
|
| CONNECTIVITY |
|---|
| Number of USB Ports |
1 |
| Number of WAN ports |
1 |
| Number of Antennae |
2 |
| LAN |
RJ-11 |
| Antennae |
2 |
| Number of LAN ports |
3 |
|
| NETWORK FEATURES |
|---|
| Frequency |
2.4 GHz |
|
| SECURITY |
|---|
| Encryption |
Wireless Access Control (Wireless MAC Filter), Wireless Security: Enable/Disable, 64/128-bit WEP; WPA-PSK/WPA2-PSK |
|
| POWER |
|---|
| Power Supply |
Input: 100 - 240 V, 50/60 Hz, Output: DC 9 V Equal to 1 Amps |
|
| GENERAL |
|---|
| Brand |
Tenda |
| In The Box |
D303, Power Adapter, Quick Install Guide, 1 x Ethernet Cable, ADSL Splitter, 2 x Phone Cords |
| Type |
3G Routers & Pocket Routers |
| Model |
TE-D303 |
| Controls |
1 x Reset/WPS, 1 x Power |
| LED Indicator |
Power, SYS, Internet, DSL, WLAN, LAN, WPS, USB |
|
| SUPPORTED PROTOCOLS |
|---|
| Standard IEEE |
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3u, IEEE 802.3, ANSI T1.413, ITU G.992.1, ITU G.992.2, ITU G.992.3, ITU G.992.5, CDMA2000, WCDMA |
|
